Series CHE / CHD
• 20 through 100mm Bore Sizes
• Stroke Lengths to 150mm
• Operating Pressure to 207 bar
• 4 Different Rod Ends Available
Series HMI
• Bore Sizes 25 through 200mm
• ISO 6020/2 Interchangeable
• 12 Standard Mounting Styles
• 210 Bar Hydraulic Pressure
Series RDH
• 1.50 through 8.00 Bore Sizes
• Gross stroke available in any
practical length
• Operating Pressure to 3,000 psi
• 9 Standard Mounting Styles
Parker Hannifin’s Industrial Cylinder Division offers
products that are designed to meet and exceed
the most demanding application requirements.
Our extensive product line offers OEM’s and End Users hydraulic and pneumatic cylinder
solutions that provide value through reduced maintenance, increased productivity, and long
service life. Parker Industrial Cylinder’s wide breadth of product encompasses NFPA, ISO, and
Custom designed products in a multitude of configurations and sizes.
Series 2A
• Bore Sizes from 1.00” to 14.00”
• Pressures to 250 psi
• 17 Mounting Styles
• High-temp capability (400°F)
Series 3L
• Bore Sizes 1.00” to 6.00”, 8.00”
• Pressures to 1000 psi
• 14 Mounting Styles
• High-temp Capability (400°F)
Series 2H
• Bore Sizes 1.50" through 6.00"
• 3000 psi Hydraulic Service
• 16 NFPA Mounting Styles
• Specials to Order
